Gas module boiler. Compared to traditional boilers

A new type of commercial gas boiler, also known as a commercial gas module boiler. Compared with traditional boilers, modular boilers have strong advantages. Let's first understand the advantages and characteristics of modular boilers.

1、 Commercial gas module furnace:

1. Gas boiler modular combination system. Commercial gas boilers consist of multiple modular boilers to form a heating system, providing heat as needed. Fully utilize the superior performance of the module, with high thermal efficiency and significant energy-saving effects; Each module works independently, and the failure of a single unit does not affect the movement of the entire system, without the need to backup the boiler.

2. Commercial gas module boiler high-efficiency silent burner gas boiler module high-efficiency stainless steel combustion grate, forced combustion, silent combustion without vibration, ensuring a quiet environment, suitable for various installation sites. The boiler uses 20mbar standard municipal low-pressure natural gas, without the need to build an independent pressure regulating station, reducing pipeline investment and saving engineering costs.

3. Commercial gas module boiler high-performance proportional combustion system. The commercial gas boiler is equipped with advanced proportional electromagnetic gas valves, which automatically adjust the output power according to the actual heating amount, and the gas pressure switch monitors the gas supply pressure in real time; The secondary gas valve monitors combustion safety in real-time to ensure safe and reliable system operation.

4. The "back-to-back" design of commercial gas module boilers saves space. The gas boiler is equipped with a unique "back-to-back" design, where one or more back-to-back modules form a heating system. Each system can be installed in parallel, with a small volume and no need to reserve lifting holes, saving space in the boiler room.

5. Commercial gas module boilers are safe and reliable. The open installation module boiler water pressure system not only maintains normal pressure during operation, but also has multiple comprehensive safety protection functions: flameout protection; Anti dry burning protection; Anti freezing protection; Low water level protection; Automatic exhaust protection; Anti overheating protection and leakage protection; Closed installation: The closed waterway system is always under a pressure of 0.05~0.3 MPa during operation. In addition to the safety protection function of open installation, the system also has the following protection functions: pressure expansion protection system; Low voltage protection system for waterways and safety relief protection device during high voltage.

6. Commercial gas module boilers are started in stages, resulting in significant energy savings. The gas boiler module system uses a graded start function to automatically adjust the start and stop of modules according to the size of the system's thermal load. When each module reaches full load, another module is restarted to ensure that the system's output heat always matches the actual demand heat load, ensuring that each boiler operates at the highest efficiency state, maximizing the thermal efficiency of the entire system, and completely solving the problem of energy waste in traditional large-scale boiler operation. At the same time, the control system automatically balances the working time of each module, extending the overall service life of the system.
